Whats in the box?

Comar R500Ni with WiFi

The Comar R500Ni with WiFi is an AIS receiver interfaced to a Raspberry Pi™ 3 computer. The R500Ni is designed for coastal monitoring applications and is capable of filtering and processing AIS data and forwarding it across a network. In this way, several R500Ni units can be used to form a complete networked monitoring solutionfor monitoring a port and its approaches.

The unit has both WiFi and Ethernet connectivity, as well as 4 USB ports and an HDMI connector for a monitor display. What makes the R500Ni different from other receivers is that it can be deployed in any AIS network using proprietary software specific to that network and is shipped ‘bare bones’.

The R500Ni is designed for use by the commercial market and uses Comar’s well proven and internationally specified high sensitivity dual channel parallel receiver.

The R500Ni from Comar Systems: Quite possibly the most flexible and powerful AIS receiver available today.

Comar AV400 Heavy Duty Commercial GRP Antenna

Overview

The AV400 Heavy Duty Commercial GRP Antenna is an omni-directional antenna, specifically designed so that the user can dedicate one antenna for the narrowband frequency specified for AIS (Automatic Identification System). Using a dedicated antenna helps to eliminate interference from nearby VHF channels.

Features

Omnidirectional
Designed for AIS
Rugged GRP Tube
Closed cell foam and epoxy resin sealed
Supplied complete with 2 mast clamps
Watertight

Applications

Installation on board commercial vessels
Shoreside monitoring stations where a rugged AIS antenna is critical

Physical

Weight: 1.6 kg
Dimensions: L 1.6 m
Mounting: Mast Clamps
Construction: GRP
Finish: White
Sections: 1

Electrical

Antenna Impedance: 50 Ω
Cable: 1m of RG-213 cable
Connections: N jack

Operational

Frequency range: 161.975 – 162.025 MHz
Gain: Unity
VSWR: <1.5:1 at resonance

Environmental

IP Rating: IP67
Operating Temp: -15°C to +55°C
Compass: Safe Distance 50 cm

Additional

Supplied: x2 MDM 207 Mast Clamps
